Low Voltage 0.6/1KV Copper Or Aluminium Conductor Armoured Or Unarmoured Power Cable

Low Voltage 0.6KV 1KV Copper or Aluminium Conductor Armoured or Unarmoured Power Cable

Model   LV0.6

Product Description

Application and Description

For use in fixed installations in industrial areas, buildings and similar applications.
Standard and Approval
IEC60502-1

Cable Construction
Conductors:
Annealed copper conductor or aluminium conductor, circular compacted stranded class 2 acc. to IEC 60228
Insulation:
Cross-linked polyethylene XLPE,PVC
Bedding:
PVC,or LSOH (special low smoke zero halogen compound)
Armour:
Single layer of galvanized steel wires or steel tape applied spirally over the bedding (SWA) for multi-core cable; Aluminim wire or aluminium tape for single core cables
Sheath:
PVC, PE or LSOH.Flame retardant, UV resistance, or termite-protection is optional

We have many years of experience in the manufacturing and sales of low voltage copper power cable.Our team regards quality and service as the life and death line of the company. Our company has been operating for many years and our copper conductor power cable has a good reputation among our customers. We provide our customers with one-stop services including design, manufacturing, and transportation. If you would like to know about our aluminum conductor armored power cable sales policy, please click"Send Message"to contact us.

Technical Characteristics

Colour of sheath: black
Core identification: HD 308 S2
Other colors available at customer request
2-core: brown, blue
3-core: brown, black, grey
4-core: blue, brown, black, grey
5-core: green-yellow, blue, brown, black, grey
auxiliary cables: white with black numbering
Maximum conductor operating temperature: +90°C
Lowest ambient temperature for fixed installation: -40°C
Lowest installation temperature: 0°C
Maximum short-circuit conductor temperature: +250°C
Smoke emission: BS EN 61034-2
Corrosive and acid gas emission: BS EN 60754-1, HCL ≤ 0,5%
Minimum bending radius: 6 x D for cables with circular copper
conductors D – overall diameter of the cable
Test voltage: 3.5kV
