APPLICATION: 0.6/1 kV XLPE Insulated, LSOH (SHF1) Sheathed Flame Retardant Power & Control Cables 0.6/1 kV IEC60092 STANDARD Offshore & Marine unarmoured power & control cables are used on board of ships in all locations for fixed installations not subject to mechanical risk complying with IEC standards 60092-352. These cables are flame retardant, low smoke & halogen free.

MariTox Marine Flame Retardant Power & Control Cable

Model   MARI

Product Description

After introducing the international advanced technology, Leistung Energie researched MariTox Marine Flame Retardant Power & Control Cable based on several years’ design and manufacturing of low voltage power cable. The product adopts novelty design and advanced manufacturing technique. It represents energy-conversation, environmental protection philosophy for the production, usage and lifetime. It’ s green energy saving product for Equipment & systems construction and upgrading.

a.Temperature range:
during installation:
fixed installed: -30 °C up to+90 °C
at short circuit of max. 5 s: 250
b.Nominal voltage: 0.6/1 kV
c.Test voltage: 3500V
d.Minimal inner bending radius: 6×OD (OD>25mm); 4×OD (OD ≤25mm)
